Two transmitters, one receiver: Supports one set of speakers to be paired with two MC05B microphones simultaneously.
Bluetooth Speaker Mode: Supports bluetooth wireless connection, allowing audio sharing from mobile devices - Supports a password mode to prevent unauthorised student connections.
Specifications:
DC In x 1:For power supply.
Power Switch x 1:Turn on/off the device.
Audio Port:Main and sub speaker audio connection port.
Mic In 1:Microphone signal input.
Audio In 1:Audio input.
Audio Out 1:Audio output.
USB 2.0 1:Port for speaker firmware upgrade only.
LED Indicator x 1:Power indicator / pairing indicator light.
Speaker Sensitivity:85dB (1W/1M).
Rated Power:240W@422.
Frequency Response:70 Hz ~ 18 KHz.
Signal-to-Noise Ratio (SNR):= 83dB (rated power, A-weighted).
THD+N:= 1% @1W/1kHz.
Static Noise Level:= 1.5mVrms @ maximum power, with input signal.
WiFi Broadcasting:Supported.
Transmission Frequency Band:2.412 ~ 2.484GHZ / 5.18 ~ 5.815GHz.
Bluetooth Version:5.0 Supported.
Input Power:100~240 Vac 50/60Hz 1.2A.
Rated Power:80W.
Product Dimension (L x W x H):340 x 230 x 193 mm.
Package Dimension (L x W x H):530 x 405 330 mm.
Net Weight:11 kg.
Gross Weight:13 kg.
Operating Temperature:0? ~ 40?.
Storage Temperature:-20? ~ 60?.
Operating Humidity:10% ~ 90% RH.
Storage Humidity:10%~ 90% RH.
Altitude:Below 5000 m.
Power Cable 1.
LINE IN Audio Cable 1.
Main and Sub Speaker Connection Cable 1.
Constant Voltage Audio Phoenix Connector (Optional) 1.
Installation Accessory Kit 1.
Specifications
General
Manufacturer
Maxhub
Brand
Maxhub
MPN
SS30B
All Supplier Codes
MHSS30B
Barcodes
GTIN
