A wide 178 horizontal and 178 vertical viewing angle
Supports both HDMI and VGA signal input
Anti-blue light technology helps protect your eyes from strain and injury
Elegant thin-frame design with a sturdy metal base
Specifications
Model: DHI-LM22-B201S
LCD Technology: IPS
Backlight: ELED
Screen Size: 21.45 inch
Aspect Ratio: 16:9
Viewing Size: 478.656 (H) 478.656 (V) mm
Screen-to-Body Ratio: =90%
Viewing Angle: 178 (H) / 178 (V)
Display Mode: Horizontal
Pixel Pitch: 0.2493 mm 0.241 mm
Pixels Per Inch: 102.7
Resolution: 1920 (H) 1080 (V)
Refresh Rate: 100 Hz
Display Color: 16.7M colors
Color Gamut: 72% NTSC
Brightness: 250 cd/m (max)
Contrast Ratio: 1000:1
Response Time: OD 5 ms
Lifespan: 30,000 hrs
Surface Treatment: Haze 25%, 3H
Low Blue Light: Software blue light protection
Device Ports
Input: 1 HDMI 1.4 (1920 1080@100 Hz), 1 VGA
Output: 1 Audio out
Speaker: 2 1 W
Power & Environmental Conditions
Power Supply: 12 VDC, 2 A
Power Consumption: 15 W (basic), 17 W (typ.), 19 W (max)
Standby Power Consumption:
Specifications
General
Manufacturer
Dahua
Brand
Dahua
MPN
DHI-LM22-B201S
All Supplier Codes
DHILM22B201S
Barcodes
6923172568564
GTIN
6923172568564
